Description
BRX3000-PRO is an AX3000M WiFi6 MESH networking router, the chip solution for the MT7981BA + MT7976CN + MT7531AE combination, to meet the growing demand for access to mobile terminals and IOT IoT nodes, which can greatly improve the user’s experience of wireless Internet access.
MESH networking, multi-node cascade, power-on automatic correlation to cover the needs of large households for wireless network use. power-on automatic correlation covers the needs of large users for wireless network.
Automatic correlation at power on to cover the needs of large users for wireless network. This AX3000 WIFI 6 Router provides up to Gigabit medium optical fiber access to meet the transmission bandwidth requirements of VR/AR/4GK/8K online video streaming.
Thanks to the latest 802.1ax WiFi6 technology platform, a single MESH node can cover up to 200 square feet of space and provide better wireless signal and network bandwidth. It provides future-proof technology, higher network efficiency, faster Wi-Fi speed, and larger coverage area, providing users with a better network experience.
| hardware characteristics | |
| Chip program | MT7981BA+MT7976CN+MT7531AE |
| WiFi protocol standards | IEEE 802.11b、IEEE 802.11g、IEEE 802.11a、IEEE 802.11n、IEEE 802.11ac、
IEEE 802.11ax、IEEE 802.3、IEEE 802.3u、IEEE 802.3x |
| Interface | 1 10/100M/1000M WAN port, support Auto MDI/MDIX
2 10/100M/1000M LAN ports, support Auto MDI/MDIX |
| button | MESH (press for 1 second)
Reset (press and hold for 5 seconds) |
| LED | WIFI signal indicator, power indicator |
| Antennas | Built-in omni-directional 5dbi gain non-removable antenna |
| Number of antennas | Built-in 5 WiFi antennas |
| Power supply | DC 12V/1A |
| Wireless features | |
|
basic functions |
wireless enable/disable
SSID Broadcast Enable/Disable Channel Selection: 1 ~ 13 (2.4G) 36 ~ 48 + 149 ~ 165 (5GHz) 2.4G bandwidth: 20MHz, 40MHz 5G bandwidth: 20MHz, 40MHz, 80MHz, 160MHz |
| 2.4G Frequency | 2412~2472MHz |
| 5G Frequency | 5180~5350MHz 5745MHz~5825MHz |
Welcome to talk more details for this AX3000 WIFI 6 Router, send inquiry now!
